PosiTest® LPD – Low Voltage Pinhole Detector for Metal and Concrete Coatings

Description

PosiTest® LPD – Low Voltage Pinhole Detector for Metal and Concrete Coatings

The PosiTest® LPD is a reliable low-voltage pinhole detector designed to locate holidays, pinholes, and coating discontinuities on metal and concrete substrates. Built for precision and durability, it helps ensure complete coating coverage and corrosion protection in compliance with international standards.

Key Features:

• Detects pinholes, holidays, and discontinuities in coatings on metal and concrete.

• GroundSense™ technology provides visual confirmation of proper grounding for accurate testing.

• Four selectable voltage outputs for compatibility with multiple test standards.

• Rugged IP65-rated enclosure – weatherproof, dustproof, and shockproof for dependable field use.

• Environmentally sealed design for enhanced durability.

• Includes a Certificate of Calibration traceable to NIST (Long Form).

• Backed by a two-year warranty for long-term reliability.

• Conforms to international standards: ISO 14654, ISO 29601, ISO 8289-A, ASTM G62, ASTM G6, ASTM D5162, BS7793-2, NACE TM0384, NACE SP0188, AS3894.2, JIS K 6766, and others.

Specifications:

• Voltage Settings: 9V ±5%, 67.5V ±5%, 90V ±5%

• Sensitivity Range: 80k–400k ±3%

• Coating Thickness Range: 0–500 μm (0–20 mils)

• Temperature Range: –10 to 50°C (14 to 122°F)

• Battery Life: Over 150 hours (depending on battery type)

• IP Rating: IP65 (weather and dust resistant)

• Dimensions: 27 × 6 × 5.5 cm (10.6″ × 2.3″ × 2.1″) without wand

• Weight: 180 g (6.4 oz) without batteries
